Gigabyte main board desktop amd a320m-h rev 3.0 (am4 2xddr4

Fisa tehnica

Garantie

36

Dvi

1 (dvi-d)

Hdmi

1 (hdmi (type a))

Produse returnabile aflate in garantie

Yes

Criterii de validare a garantiei

Serial number

Greutatea bruta a pachetului

1 kg

Greutatea neta a pachetului

0.5 kg

Bucati in pachet

1

Greutatea bruta a cutiei

1 kg

Retail packaging net weight carton

0.1 kg

Retail packaging net weight plastic

0.1 kg

Pachete (colete) in cutie

1

Tip pachet

Retail

Locatia dispozitivului

Integrated

Factor de forma

Micro atx

Inaltime

195 mm

Latime

244 mm

Termen de garantie

36 luni

Adancime pachet

244 mm

Grosimea pachetului

195 mm

Inaltime pachet

40 mm

Standard soclu procesor (cpu)

Socket am4

Cpu capacitate maxima suportata

1

Tip memorie

Ddr4 sdram

Factor de forma a memoriei

Dimm 288-pin

Viteza de memorare

2133mhz(pc4-17000) ,2400mhz(pc4-19200) ,2667mhz(pc4-21300)

Ofera metode de corectie a erorilor

Ecc/non-ecc

Capacitatea maxima de stocare a memoriei sistem ce poate fi instalata

64 gb

Cantitatea totala de sloturi de memorie

2

Caracteristici memorie

Unbuffered ,dual rank ,single rank ,xmp

Integrated

Bstorage controller:/b,supports: level 0, level 1, level 10,sata iii-600 (4),bstorage controller:/b,pcie/sata (1 x m.2 (key m)),

Lan

1 (rj-45)

Suport protocol legatura date

Gigabit ethernet/fast ethernet/ethernet

Chipset

Amd a320

Usb 2.0

2 (usb 2.0 (type a))

Audio output mode

7.1 channel surround

Standard audio

High definition audio

Audio interface

3 (3.5-mm minijack)

Ps/2

2

Prevazut cu cpu

Amd athlon ,amd ryzen series 2nd generation ,amd ryzen series 1st generation ,amd ryzen series 3rd generation ,amd athlon x4

Lan integrated

Yes

Bios type

Ami

Bios features

Gigabyte q-flash ,gigabyte xpress install ,wfm 2.0 support ,pnp 1.0a support ,uefi ,smbios 2.7 support ,dmi 2.7 support ,acpi 5.0 support

Hardware monitoring

System temperature ,system voltage

Software inclus

Norton internet security (oem version)

Audio integrated

Yes

Power connectors type

24+8 pin

Supported operating system

Microsoft windows 10 pro 64-bit (license)

Usb 3.1 gen 1

4 (usb 3.1 (type a))

Mainboard features

Fan speed control

Pci express x16

1

Pci express x1

2
